The MAN B&W 6S80ME-C9 engine with integrated EGR pictured at Hyundai. Image: MAN B&W
MAN Diesel & Turbo, together with HHI-EMD, the engine and machinery division of Hyundai Heavy Industries, has presented the first IMO Tier III-compliant diesel engine utilizing EGR (Exhaust Gas Recirculation). The presentation of the engine took place at HHI-EMD production facilities in Ulsan, South Korea on 9 October 2012 when a group, representing shipyard and ship owners, was invited to an informal presentation of the new engine type – a MAN B&W 6S80ME-C9 with integrated EGR.
The EGR system represents a milestone in Tier III development that enables the engine to meet IMO Tier III NOx regulations, which will be introduced in ECAs (Emission Controlled Areas) from 2016. The new development means that this strict emissions limit can be met without significantly compromising engine performance. In this respect, MAN Diesel & Turbo’s SÃ¸ren H. Jensen, Vice President and Head of Research & Development, Marine Low-Speed, said: “Testing achieved a low penalty, equivalent to 1-3g/kWh, which is even better than our most optimistic expectations.”
The EGR system was designed, produced and assembled in close cooperation with HHI-EMD, Alfa Laval, Siemens, GEA and Vestas Aircoil. This close cooperation has ultimately resulted in a reliable prototype engine configuration that MAN Diesel & Turbo states will form the basis for its future low-speed diesel programme.
SÃ¸ren Jensen further stated: “As a promising spin-off benefit, the engine can also run in a fuel-optimised Tier II mode that facilitates an approximate 4 g/kWh fuel-oil consumption reduction at part-load.” As such, MAN Diesel & Turbo reports that this makes the engine even more efficient than today’s high efficiency Tier II engines during transoceanic operation. This favourable result was accomplished through a combination of sequential turbocharging, turbocharger cut-out and low EGR rates.
The engine will be installed in a Maersk Line C-class container vessel, currently under construction at Hyundai’s shipyard. The ship is due for delivery in the first quarter of 2013 and is bound for service between South East Asia and West Africa. The A.P. Moller – Maersk Group and MAN Diesel & Turbo have agreed to operate the engine 20% of the time in IMO Tier III mode, and to otherwise favour the fuel-optimised Tier II mode with low EGR rate. MAN Diesel & Turbo intends to follow the engine’s performance closely over the next three years in order to gain service experience and increase the EGR system’s reliability for future engines.
