Improve EEDI Ratings with Climeon HeatPower 300 Marine

Improve EEDI Ratings with Climeon HeatPower 300 Marine

gCaptain
Total Views: 270
June 7, 2022

Commissioning a new vessel allows operators to expand their fleet and increase profitability with additional resources but the design of a ship has a major impact on its subsequent performance and revenue-making capabilities. With increasing environmental regulations, such as the Energy Efficiency Design Index (EEDI), new-build ships must be designed with their environmental impact in mind.

What is the Energy Efficiency Design Index?

First introduced alongside Ship Energy Efficiency Management Plans (SEEMPs) in 2011, the EEDI regulations require new-build vessels to achieve a ‘minimum energy efficiency level per capacity mile’ (Resolution MEPC 203 (62), MARPOL Annex VI).

The EEDI measures design efficiency, as opposed to operational efficiency, and is the most important technical measure for new-build vessels (IMO). To comply with the EEDI, a ship must meet the requisite standard for its type and size, expressed in grams of CO2 per capacity mile (sometimes referred to as ‘transport work’ or ‘tonne mile’.).

Therefore, each ship has a:

  • Required EEDI (the EEDI standard they must meet), and an;
  • Attained EEDI (the actual EEDI rating the vessel is given).

Providing a ship’s Attained EEDI is equal to or better than its Required EEDI, it will be deemed compliant with the Energy Efficiency Design Index.

A complex formula is used to calculate a ship’s Required EEDI and Attained EEDI but, in simple terms, it can be expressed as follows:

EEDI Calculation Graphic

How Are EEDI Regulations Implemented?

The EEDI increases the energy efficiency of the industry by setting required technical efficiency standards for new vessels based on an established reference line (baseline). Historical emissions data has been used to set this baseline and, according to EEDI regulations, new vessels must achieve a reduction in terms of percentage.

EEDI: In Practice

Simple graphic showing Phase 1-4 EEDI implementation

For example, gas carriers above 15,000 DWT were required to reduce CO2 emissions by 10% compared to the relevant segment baseline under phase 1 of the EEDI. When phase 2 of the EEDI was introduced, the requisite reduction percentage was 20% and now, under phase 3, gas carriers above 15,000 DWT must reduce CO2 emissions by 30% in comparison with the relevant baseline.

Although the EEDI has been in force for some time, its requirements have been strengthened incrementally with new phases being introduced every few years. With more vessels now subject to the Energy Efficiency Design Index and ships facing lower emissions output standards, it’s more important than ever for shipowners, shipyards and design houses to use the latest maritime technology to increase energy efficiency and reduce CO2 emissions.

Phase 3 of the EEDI Brought Forward to April 2022

Originally, phase 3 of the EEDI was scheduled to come into force in 2025. In a bid to accelerate the decarbonization of the shipping industry, however, the IMO brought the implementation of Phase 3 forward to April 2022 and strengthened the regulations even further ((Resolution MEPC 324 (75)2021 Revised Marpol Annex VI, Resolution MEPC 328 (76)).

Following the latest resolution, many vessels will need to meet enhanced emissions reductions. While there are various exclusions which may apply to specific vessels, the regulations broadly require the following reductions:

However, these aren’t the only types of vessels that will face increasingly stringent EEDI requirements. Set to come into force in 2025, a second iteration of Phase 3 demands the following reductions

Meeting EEDI Requirements

As environmental regulations tighten across the board, it’s vital that shipowners use the latest innovations to achieve the requisite EEDI rating for their vessels. To date, various methods have been used to optimize vessel energy efficiency and, therefore, improve EEDI ratings, including:

  • Reducing hull resistance
  • Increasing propeller efficiency
  • Slow steaming
  • Low-carbon fuels
  • Optimizing routes and operating patterns

As you can see, there are many ways to increase a ship’s energy efficiency and shipowners have been forced to steadily embrace more sustainable shipping methods in order to achieve EEDI compliance thus far. However, the acceleration of Phase 3 and the drive towards the decarbonization of the shipping industry (Economist Impact, 2021) means that additional solutions will need to be implemented.

As the EEDI is concerned with the energy efficiency of a ship’s technical design, rather than its operation (which is assessed via other measures, such as the Energy Efficiency Operational Indicator (EEOI) and Carbon Intensity Indicator (CII), it follows that technical efficiency can be improved by using onboard technologies.

Ship wire model 3D illustration.

Ship wire model 3D illustration.

Furthermore, integrating new technologies into new-build ships can actually be far easier than retrofitting them onto existing vessels, which gives shipowners striving to achieve optimal EEDI ratings an advantage over those who are battling to achieve requisite EEXI ratings.

However, selecting the right onboard technologies is critical to improving energy efficiency, maintaining crew and passenger safety and achieving optimal vessel performance.

Waste Heat Recovery for EEDI Compliance

Although shipowners are using new forms of tech to improve the energy efficiency of new-build vessels, there is one type of technology that is often overlooked: waste heat recovery (WHR). Despite this, marine WHR can be used to successfully increase energy efficiency and, therefore, enable shipowners, shipyards and design houses to achieve Required EEDI ratings.

What Is Marine Waste Heat Recovery?

Marine waste heat recovery essentially means that onboard waste heat is captured, repurposed and used to generate clean, carbon-free electricity. This power is then used by the ship’s grid, which means it is less reliant on diesel-powered generators. As a result, less fuel is used and fewer CO2 emissions are released, which helps to enhance the EEDI rating of the vessel.
